Hot sell fanless design J6412 mini pc with three display 3*i225-V 2.5G LAN micro computer for office
Hot sell fanless design J6412 mini pc with three display 3*i225-V 2.5G LAN micro computer for office
Couldn't load pickup availability
Hot sell fanless design J6412 mini pc with three display 3*i225-V 2.5G LAN micro computer for office
Pls contact me directly:(Skype:iwilljennifer, Whatsapp/WeChat:+86 18899771696, QQ:2853375779)
1) In-tel cel-eron J16412 quad core 2.0GHz
2) 2*DP+1*HD Port+3* Inel 2.5g LAN+1*COM+3*USB2.0+3*USB3.1
3) support Auto power on when there is electricity,Timing boot,Wake on LAN,PXE boot, watchdog (level 0-255), TPM2.0 security encryption
4) High-quality pure aluminum Case
5) 1*MSATA,1*mini-PCIE, support wifi and BT
6) 3*In-tel i225-V 2.5G LAN
7) DC-IN 12V power supply and AC power adapter
8) Applied in Digital signage, KIOSK, Advertising Machine, Self-service Terminal,
Electronic Whiteboard, ATM, POS/Retail, Networking, Automation, Surveillance
Parking Pay Station, Channel System, Medical electronic etc
| Hot sell fanless design J6412 mini pc with three display 3*i225-V 2.5G LAN micro computer for office |
|||
| Model |
NANO-N1121 |
||
| Case Color |
Metal gray (color can be customized) |
||
| Material |
High-quality pure aluminum |
||
| CPU |
Adopt In-tel Cele-ron J6412 quad core 2.0GHz |
||
| CPU Architecture |
Elkhart Lake |
||
| Mainboard |
120*120mm mini itx mainboard |
||
| RAM |
1*DDR4 3200MHz SODIMM, Max 32 GB |
||
| Storage |
1*M.2 2280 slot,1*2.5 inch HDD/SSD 16G/32G/64G/128G/256G/512G SSD (optional 500~1T HDD ) |
||
| Audio |
Integrated Realtek ALC662 6sound channel |
||
| Display Interface |
1*HD Port,2*DP Port |
||
| Display |
In-tel(R) UHD Graphics, support DP, HD Port, display input |
||
| I/O |
USB |
3*USB3.1, 3*USB2.0 |
|
| COM |
1* COM |
||
| SIM card slot |
1 |
||
| Lan |
3*2.5G Lans |
||
| Audio(Mic and Speaker) |
1 |
||
| Network Card |
3*In-tel i225-V 2.5G LAN |
||
| Expansion |
1*M.2 2280 M-key slot( support SATA protocol) |
||
| 1*M.2 3052 B-key slot(USB3.0 signal,support 4G/5G),1*SIM slot |
|||
| 1*M.2 2230 E-key slot(support WIFI, BT | |||
| Other Function |
Support Auto power on when there is electricity,Timing boot,Wake on LAN,PXE boot, watchdog (level 0-255), TPM2.0 security encryption |
||
| Power Supply |
DC 12V-IN power supply and AC power adapter |
||
| Operating System |
Win 10 /Win 11, Linux |
||
| BIOS |
AMI UEFI BIOS |
||
| Working Temperature |
0℃ ~ +40℃(Commercial HDD),-20℃ ~ +60℃(Industrial SSD),Surface air flow |
||
| Working Humidity |
0% - 95% relative humidity, Non-condensing |
||
| Size |
150 * 126.5 * 45 mm (W*D*H) |
||
| Weight |
0.84kg |
||
