BeonStore
HLY Computer i5 7267U 4200Y 4GB RAM 120GB SSD VGA WiFi office use Small Tower Desktop computer i3 i7 Mini PC for Win10
HLY Computer i5 7267U 4200Y 4GB RAM 120GB SSD VGA WiFi office use Small Tower Desktop computer i3 i7 Mini PC for Win10
Regular price
$712.99 USD
Regular price
$0.00 USD
Sale price
$712.99 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Product Description
HLY i5 7267U 4200Y 4GB RAM 120GB SSD VGA WiFi office use Small Tower Desktop computer i3 i7 Mini PC for Win10
|
MODEL+ PROCESSOR
|
SPECIFICATION
|
|
H35 I5 4200Y DDR3
|
1.Intel Core i5-4200Y Processor (3M Cache, up to 1.90 GHz)
|
|
2. 2 Core 4 Thread
|
|
|
3. Intel HD Graphics 4200
|
|
|
H35 I5 4200U DDR3
|
1.Intel Core i5-4200U Processor (3M Cache, up to 2.60 GHz)
|
|
2. 2 Core 4 Thread
|
|
|
3. Intel HD Graphics 4400
|
|
|
H35 I5 6260U DDR4
|
1.Intel Core i5-6260U Processor (4M Cache, up to 2.90 GHz)
|
|
2. 2 Core 4 Thread
|
|
|
3.Intel Iris Graphics 540
|
|
|
H35 I5 6260U DDR3L
|
1.Intel Core i5-6260U Processor (4M Cache, up to 2.90 GHz)
|
|
2. 2 Core 4 Thread
|
|
|
3.Intel Iris Graphics 540
|
|
|
H35 I5 7267U DDR4
|
1.Intel Core i5-7267U Processor (4M Cache, up to 3.50 GHz)
|
|
2. 2 Core 4 Thread
|
|
|
3. Intel Iris Plus Graphics 650
|
Product Paramenters
|
Memory Type
|
Technology
|
DDR3L-1600MHz (i5 4200U/ i5 4200Y） DDR4-2133（i5 6267U/ i5 7267U）
|
|
Max Capacity
|
Up to 16GB
|
|
|
Socket
|
1* 204-pin SDSIMM
|
|
|
Display
|
VGA
|
Maximum support resolution 1920 x 1080p@24MHz
|
|
HD
|
Maximum support resolution 3200×2000@24Hz
|
|
|
Dual Display
|
Support Dual-Line Synchronous or Independent display
|
|
|
Ethernet
|
LAN
|
10/100/1000/ Mbps Realtek 8111F,Support network wake up
|
|
WIFI
|
WIFI Module
|
with dual antennnas, 300M, 802.11.b/g/n
|
|
Audio
|
Chipset
|
Apply Realtek ALC662Audio control chip, support for two channels, stereo，Line out
|
|
Expansion
|
Mini PCIe
|
1 x Half size Mini-PCIe
|
|
Storage
|
mSATA
|
1 x Full size mini PCIe slot
|
|
Other
|
Watchdog time
|
Supports (If you need this hardware, please let us know before payment)
|
|
Software
|
OS
|
win-8/ win-10/ Linux/ ubuntu/ Centos etc.
|
|
Power Consumprtion
|
Power Type
|
DC-IN 5.5*2.5
|
|
Power Adapter
|
DC 12V5A/ 60W (AC TO DC, 100~240V)
|
|
|
TDP
|
11.5-28W
|
|
|
I/O
|
USB
|
2 x USB2.0 4x USB3.0
|
|
VGA
|
1
|
|
|
HD
|
1
|
|
|
LAN
|
1
|
|
|
MIC
|
1
|
|
|
SPK
|
1
|
|
|
Physical Charateristics
|
Case Material
|
Aluminum Alloy
|
|
Installation
|
Wall/ Desktop
|
|
|
Dimensions
|
134x 127 x40mm
|
|
|
Weight
|
2.0KG
|
|
|
Enviroment
|
Operating Temperature
|
-20℃~65℃
|
|
Storage Temperature
|
15-35℃
|
|
|
operating humidity
|
5%-95% Relative humidity, no condensation
|
